Industrial kov vaj huam sib luag Chaw tsim tshuaj paus|PCAP & Resistive Touch Solutions (2.4 "–55")
Peb yog cov kws tshaj lij kev lag luam kov vaj huam sib luag tsim tshwj xeeb hauv Projected Capacitive (PCAP) thiab cov thev naus laus zis tiv thaiv rau qhov xav tau ib puag ncig.
Peb cov kev daws teeb meem yog tsim los rau kev lag luam HMI, cov khoom siv kho mob, EV them chaw nres tsheb, kiosks, POS terminals, thiab cov khoom siv tswj hwm, kom ntseeg tau tias kev ua haujlwm ruaj khov, kev siv lub neej ntev, thiab kev txhawb nqa OEM / ODM tag nrho.
Nrog rau hauv - tsev tsim los ntawm 2.4 "mus rau 55", peb muab kev txhawb nqa engineering tiav los ntawm kev tsim qauv rau kev tswj xyuas thiab kev sib koom ua ke zaum kawg.
Tshawb xyuas Peb Cov Khoom Siv Tshuab Kov
Txhua lub tshuab kov yog tsim los ntawm kev siv ib puag ncig, EMI cov xwm txheej, thiab cov kev xav tau ntawm cov neeg siv.
|
Technology |
Zoo tshaj rau |
Cov yam ntxwv tseem ceeb |
|
Qhov projected Capacitive (PCAP) |
Kev kho mob, siab-kawg POS, sab nraum zoov kiosks, ntsiav tshuaj. |
10- taw tes lossis ntau dua kov nrog cov lus teb ceev (<10ms typical) Ntug-rau- ntug iav tsim rau niaj hnub HMI kev koom ua ke High durability iav qauv nrog IK08-IK10 xaiv kev tiv thaiv Kev ua haujlwm ruaj khov nyob rau hauv EMI- ib puag ncig kev lag luam hnyav |
|
Resistive (4/5/8-Wire) |
Factory automation, tub rog, hnyav machinery. |
Zero cuav- kov hauv qab dej, plua plav, roj, thiab EMI cuam tshuam Tau tshaj cov ntiv tes, hnab looj tes, stylus, thiab cov cuab yeej siv Kev ntseeg siab rau lub hom phiaj -tseem ceeb muaj kev tswj hwm kev lag luam Kev ua tau zoo heev nyob rau hauv qis - nqi thiab siab - daim ntawv thov ua haujlwm ntev |
Kov Vaj Huam Sib Luag Customization Muaj peev xwm
Los ntawm kev ntsuam xyuas thawj zaug mus rau qhov kawg kov tuning, peb txhawb nqa koj cov khoom lag luam tag nrho.
|
Customization khoom |
Muaj Kev Xaiv |
|
Qhov Loj |
2.4" – 55" |
|
Technology |
PCAP / Resistive (4-xaim, 5-xaim) |
|
Kov Cov Ntsiab Lus |
Ib leeg / Ntau- kov (Txog 10 ntsiab lus) |
|
Khob Khob Khob |
AG (Anti-Glare), AR (Anti-Reflection), AF (Anti-Ntiv tes) |
|
Interface |
USB, I2C, UART, RS232 |
|
Qauv |
G+G (Glass+Glass), G+F (iav+film), G+F+F |
|
Puab & Tsim |
Standard, Irregular Shapes, Drilled Qhov, Kauj Ruam Npog Lens |
|
Waterproof Rating |
IP65, IP67 Ua raws |
|
Bonding Solutions |
Huab cua Bonding / Optical Bonding (OCA / OCR) |
|
Tswj IC |
EETI, ILITEK, GOODIX, Microchip |
|
Logo & Printing |
Kev Cai Silk-kev tshuaj ntsuam (Organic lossis Ceramic number case) |
|
Thickness |
0.55mm txog 10mm Custom Cover iav |
Kev daws koj cov teeb meem tsim
|
Kev sib tw |
Peb Kev daws |
|
Hnub Ci Readability |
High - iav transmittance iav thiab Optical Bonding tshuab los tshem tawm cov pa tawm. |
|
Ib puag ncig hnyav |
IK08/IK10 cuam tshuam tsis kam thiab IP65/67 ntsuas dej-cov qauv pov thawj. |
|
Electromagnetic Noise |
Kev tswj tshwj xeeb tuning los tiv thaiv "Ghost Touches" hauv kev lag luam. |
|
Gloved Operation |
Kev cai firmware tuning rau phais, muaj, los yog lub caij ntuj no hnab looj tes. |
Khoom Muag Khoom: 4-Wire Resistive Touch Screen
Lub 4-xaim resistive kov npo yog qhov kev xaiv zoo tshaj plaws rau cov xwm txheej xav tau kev ua haujlwm siab thiab tswj tus nqi. Nws pom cov ntsiab lus siab los ntawm ob lub pob tshab txheej txheej, kom ntseeg tau cov lus teb ncaj qha tsis hais lub cuab yeej nkag.
|
Feature |
Specification |
|
Qauv |
Ob pob tshab conductive ITO txheej nrog insulating dots |
|
Kov Input |
Ntiv tes (liab qab / hnab looj tes), stylus, cwj mem, credit card |
|
Kev xa tawm |
Ntau dua lossis sib npaug rau 85% (Glossy), Ntau dua lossis sib npaug rau 78% (Matte) |
|
Nto Hardness |
3H |
|
Kev khiav hauj lwm voltage |
DC 5 V |
|
Ua haujlwm kub |
-20℃rau +70 degree |
|
Cia Kub |
-40℃rau +85 degree |
|
Linearity |
Tsawg dua lossis sib npaug ± 1.5% |
|
Lub neej ua haujlwm |
>1 Million touches (polyester stylus), >5 lab (rubber stylus) |
|
Environmental Sealing |
IP65 |
|
Interface |
USB, RS232 (nyob ntawm tus maub los) |
Vertical Market Applications
Kev Kho Mob & Kev Kho Mob
Cov neeg mob saib xyuas, kuaj kab mob, kev phais cuam tshuam yuav tsum muaj kev ruaj ntseg thiab EMI tsis kam.
Muaj Automation
CNC tshuab, PLC tswj vaj huam sib luag, rugged HMI interfaces nyob rau hauv lub Hoobkas ib puag ncig.
EV Charging & Sab nraum zoov Kiosks
High- brightness, waterproof, thiab vandal- tiv thaiv kov systems rau pej xeem ib puag ncig.
Smart Building Systems
Integrated kov tswj vaj huam sib luag rau HVAC, teeb pom kev zoo, thiab kev tswj hwm kev nkag.
Vim li cas thiaj xaiv MQ Screen
Cleanroom Ib puag ncig
Peb qhov kev tsim khoom siv nyob rau hauv Chav Kawm 1,000 & 10,000 chav huv huv kom paub meej qhov pom tseeb tshaj plaws thiab xoom- plua plav paug.
Cov Qauv Zoo
ISO 9001: 2015 tau lees paub cov txheej txheem tsim khoom nrog 100% AOI (Automated Optical Inspection).
Ntev -Lub Sij Hawm Muaj
Peb lav 5-7 xyoo ntawm cov khoom ruaj khov rau cov haujlwm ua lag luam, txo qis qhov xav tau kev rov ua dua tshiab -tsim.
Kev them nyiaj yug Engineering
Kev nkag ncaj qha rau peb FAE (Field Application Engineers) rau kev tswj xyuas thiab kev sib koom ua ke.
Consultative Engineering
Kev Ntsuam Xyuas Kev Xav Tau
Kev ntsuas ib puag ncig (Tub, ESD, Moisture).
Engineering Tsim
CAD kos duab thiab kev xaiv tswj rau koj lub OS tshwj xeeb.
Prototyping
Kev tsim qauv nrawm nrawm nrog cov ntawv qhia txog kev sim tag nrho.
Kev tsim khoom loj
Txhim khu kev ntsuas - nce nrog 100% QC thiab ntev - kev txhawb nqa logistics.
FAQ
Peb tau zoo-paub tias yog ib qho ntawm cov ua lag luam kov vaj huam sib luag thiab cov muag khoom hauv Suav teb, tshwj xeeb los ntawm cov khoom zoo thiab tus nqi zoo. Thov so assured mus yuav bulk customized kov vaj huam sib luag los ntawm peb lub hoobkas. Txais tos mus saib peb lub vev xaib kom paub ntau ntxiv.
